GOYOJO GR325 Thermal Imaging Night Vision Scope
$1,399.00
- Product Code: GOYOJO-THERMAL-IMAGING-GR325
- Availability: In Stock
GOYOJO GR325 Thermal Imaging Night Vision Scope
Infrared
● Detector Type: Uncooled VOx (Vanadium Oxide) Focal Plane Array
● Resolution: 384×288
● Pixel Pitch: 12μm
● Focal Length: 25mm
● Field of View (FOV): 10.5° × 7.9°
● Spectral Band: 8–14μm
● NETD (Noise Equivalent Temperature Difference): ≤40mK @25℃, F/1.0
● Frame Rate: ≤50Hz
● Focusing Method: Manual focus
Detection Range
● Human Target (1.7m × 0.5m × 0.3m): 590 meters
● Vehicle (4.5m × 2.0m × 1.5m): 1,563 meters
Recognition Range
● Human Target (1.7m × 0.5m × 0.3m): 2,361 meters
● Vehicle (4.5m × 2.0m × 1.5m): 6,250 meters
Display
● Display Type: OLED
● Resolution: 1440×1080
● Screen Size: 0.39 inches
● Digital Zoom: 1× / 2× / 4× / 8×
● Diopter Adjustment: ±5SD
● Color Palettes: White Hot, Black Hot, Fusion (Fire), Rainbow, Iron Red, Cool
● Hot Spot Tracking: Supported
● Picture-in-Picture: Supported
● Languages: Simplified Chinese, Traditional Chinese, English, Russian, German
Storage
● Built-in Memory: 16GB eMMC (actual usable space approx. 13.8GB due to system usage)
● Photo Capture: Supported
● Video Recording: Supported
● Image/Video Format: JPG / MP4
Interface
● USB Port: Charging / Data Transfer (photos and videos)
Power
● Removable Rechargeable Lithium Battery: 1400mAh ×2 (Battery Model: 18350)
General Specifications
● Total Power Consumption: ≤1.8W
● Battery Life: ≥5 hours
● Operating Temperature: -20℃ ~ +60℃
● Storage Temperature: -30℃ ~ +70℃
● Shock Resistance: ≤1000G
● Protection Rating: IP66
Dimensions / Weight
● Product Dimensions: 198 × 57.5 × 64.3 mm
● Product Weight: 580g
